Bambu ABS-GF Bambu ABS-GF is a glass fiber-reinforced ABS filament that enhances both mechanical and aesthetic properties. Compared to regular ABS, ABS-GF excels in strength, stiffness, temperature resistance, and dimensional stability. It is also less prone to deformation and warping. The addition of glass fiber creates a smooth matte finish...

Color

Categories : ABS/ASA, Fiber Reinforced, Filaments

Description
Review

Bambu ABS-GF

Bambu ABS-GF is a glass fiber-reinforced ABS filament that enhances both mechanical and aesthetic properties. Compared to regular ABS, ABS-GF excels in strength, stiffness, temperature resistance, and dimensional stability. It is also less prone to deformation and warping. The addition of glass fiber creates a smooth matte finish with micro-spot gloss, effectively reducing the visibility of layer lines. ABS-GF is ideal for producing both mechanical parts and decorative items, thanks to its inherent water resistance, wear resistance, durability, and vibrant colors.

Enhanced Strength and Stiffness

ABS-GF surpasses regular ABS in strength and stiffness, making it ideal for load-bearing and bending-resistant components.

	ABS	ABS-GF	Improvement %
Stiffness (Bending Modulus - XY)	1880 MPa	2860 MPa	52.1%
Strength (Bending Strength - XY)	64 MPa	68 MPa	6.3%
Layer Strength (Bending Strength - Z)	39 MPa	46 MPa	17.9%
Heat Resistance (HDT, 0.45 MPa)	87 °C	99 °C	13.8%

Greater Dimensional Stability

Glass fiber reinforcement provides ABS-GF with enhanced dimensional stability compared to regular ABS, reducing warping and deformation during printing. This property makes it particularly suitable for complex mechanical assembly parts or geometric components.

Specimen Test: Model size (L*W*H): 240*50*20 mm³ (the XY direction); Infill Density: 25%

Fine Matte Finish

The smooth matte finish and nearly invisible layer lines make ABS-GF perfect for decorative and finely detailed parts.

Water Resistance & Built to Last

Bambu ABS-GF offers enhanced water resistance and durability, making it suitable for producing lasting household and industrial items such as mechanical casings, connectors, and molds.

Accessory Compatibility

	Recommended	Not Recommended
Build Plate	Smooth PEI Plate, Textured PEI Plate	Cool Plate SuperTack
Hotend	Hotend with Hardened Steel 0.4mm / 0.6mm (recommended) / 0.8 mm	Hotend with Stainless Steel Nozzle All Size
Glue	Bambu Liquid Glue Glue Stick	/

ABS-GF Hex Code Table

Color	Hex Code	Display
White	#FFFFFF
Gray	#C6C6C6
Yellow	#FFE133
Orange	#F48438
Red	#E83100
Green	#61BF36
Blue	#0C3B95
Black	#000000

Parameters Comparison

Learn more different filaments comparison on Bambu Filament Guide >>

	ABS	ABS-GF	PA6-GF
Composition	Acrylonitrile - butadiene - styrene	Acrylonitrile - butadiene - styrene, glass fiber	PA6, glass fiber
AMS Compatibility	YES	YES	YES
Dry Out Before Use	Recommended	Recommended	Required
Printing Speed	< 300 mm/s	< 180 mm/s	< 130 mm/s
Printer Type	Enclosure	Enclosure	Enclosure
Toughness (Impact Strength - XY)	39.3 kJ/m²	14.5 kJ/m²	27.2 kJ/m²
Strength (Bending Strength - XY)	62 MPa	68 MPa	120 MPa
Layer Strength (Bending Strength - Z)	39 MPa	46 MPa	51 MPa
Stiffness (Bending Modulus - XY)	1880 MPa	2860 MPa	3670 MPa
Layer Adhesion (Impact Strength - Z)	7.4 kJ/m²	5.3 kJ/m²	4.1 kJ/m²
Heat Resistance（HDT, 0.45 MPa)	87 °C	99 °C	182 °C
Saturated Water Absorption Rate/%（25 °C, 55% RH）	0.65	0.53	2.56

RFID for Intelligent Printing

All printing parameters are embedded in RFID, which can be read through our AMS (Automatic Material System).

Load and print! No more tedious setting steps.

Recommended Printing Settings
Drying Settings (Blast Drying Oven)	80 °C, 8 h
Printing and Keeping Container's Humidity	< 20% RH (Sealed, with Desiccant)
Nozzle Temperature	240 - 270 °C
Bed Temperature (with Glue)	80 - 100 °C
Printing Speed	< 180 mm/s

Physical Properties
Density	1.08 g/cm³
Vicat Softening Temperature	103 °C
Heat Deflection Temperature	99 °C
Melting Temperature	202 °C
Melt Index	7.56 ± 1.4 g/10 min

Mechanical Properties
Tensile Strength	36 ± 3 MPa
Breaking Elongation Rate	6.3% ± 1.2%
Bending Modulus	2860 ± 130 MPa
Bending Strength	68 ± 4 MPa
Impact Strength	14.5 ± 1.5 kJ/m²

Downloads

Filament TDS

Filament MSDS

Filament RoHS

Printing Tips

• Drying conditions: 80℃ for 8 hrs. Dry the filament before printing to achieve higher print quality.

• To minimize warping, avoid printing large-sized high infill density models. Use enclosed printers and ensure the build plate is properly applied with glue for better print adhesion before printing. Set lower printing speed and higher heatbed temperature. For more details please refer to: Common print quality problems and solutions on WIKI.

• Similar to ABS, pungent and unpleasant odors may be released during printing. Make sure your printer is placed in a well-ventilated area and use enclosed printers.
